Description
- 5.5W RF Output for 144MHz
- 5.0W RF Output for 430MHz
- Power-On Message
- Direct Function Key
- Direct Frequency Entry
- Auto Repeater Offset
- 1750 Hz Tone Burst
- Time-Out Timer
- Battery Select (Li-ion / AAA Battery)
- Beat Shift
- Frequency Shift
- VOX Circuit included (Operation with Optional headset)
- Battery Capacity Indicator
- Wide / Narrow Deviation Selection (Per Channel)
- Busy Channel Lock-Out
Specification
General
| Frequency Range |
TX: 136 - 174 MHz RX: 136 - 174 MHz |
| Mode | F3E, F2D |
| Antenna Impedance | 50 Ω |
| Operation Temperature Range | -20 °C ~ +60 °C |
| Operating Voltage | DC 6.0 ~ 9.0 V (Standard Voltage DC 7.4 V) |
| Frequency Stability | ±2.5 ppm |
| Microphone Impedance | 2 kΩ |
| Battery Life (Hi/Mid/Low) |
with KNB-63L: 6 / 8.5 / 10.5 Hour with KNB-65L : 8 / 11.5 / 14 Hours with BT-16 : 6 / 8 / 10 Hours |
| Dimensions (W x H x D) | 54 x 111.7 x 14.4 mm |
| Weight | approx. 138 g |
Transmitter
| RF Power Output |
High: 5.5 W with BT-16: approx.3.5 W Mid: 2W Low: 1W |
| Modulation | Reactance modulation |
| Maximum Frequency Deviation | Within ±5 kHz |
| Moduration Distortion | Less than 5 % (300 Hz ~ 3 kHz) |
Receiver
| Circuitry | Double super heterodyne |
| Intermediate Frequency | 1st IF: 38.85 MHz / 2nd IF: 450 kHz |
| Sensitivity (12dB SINAD) | Less than 0.16 μV |
| Squelch Sensitivity | Less than 0.13 μV |
| Selectivity |
- 6 dB: More than 10 kHz -50 dB: Audio Output More than 10 kHz |
| Audio Output | More than 400 mW (8 Ω / 10 % distortion) |
